Inline air extractor V-10 - Ø 250mm - 1650m3/H - Aero-Fan

Aero-Fan V-10 inline air extractor - Ø 250mm, 1650 m³/h, for large volumes

Designed for high-volume ventilation systems, the Aero-Fan V-10 is a professional inline fan in 250mm format. It is capable of moving an impressive volume of air of up to 1650 m³/h. Thanks to its 7 robust blades, it ensures rapid evacuation of hot, humid or stale air, making it ideal for large indoor grow rooms.

Its compact design includes a mounting plate for easy integration into any ductwork network. What's more, it's fully compatible with TrolMaster controllers, enabling intelligent, automated management of your environment. Robust, highly efficient and enduring, the V-10 is the ultimate ventilation solution for the most demanding growers, built for high performance.

Key benefits

Exceptional air flow: Able to move 1650 m³/h, perfect for large surfaces.
Optimum efficiency: Rapid evacuation of hot and stale air for an ideal climate.
Easy integration: Compact design with mounting plate included for simple installation.
Intelligent management: Full compatibility with TrolMaster controllers for automation.
Robustness and durability: Designed for long life and intensive use.
Professional performance: Meets the needs of the most demanding indoor cultures.

Detailed features

The V-10 extractor is designed to work optimally with TrolMaster controllers. This enables fully automated management of temperature, humidity and airflow, ensuring perfect conditions for your crops.
Absolutely. Its impressive flow rate of 1650 m³/h makes it perfectly suited to large-scale grow rooms or professional installations requiring powerful ventilation.
No, installation is simplified. A mounting plate is included, making it easy to integrate the extractor into existing ductwork, whether installed in a vertical or horizontal position.
It is designed to limit noise pollution thanks to its robust, balanced structure. Although its high air volume naturally produces moderate flow noise, it remains within an acceptable range for its category.
In addition to its high air flow rate, this model stands out for its high durability, compatibility with system automation and stable operation even under variable voltage. This is a top-of-the-range product, ideal for advanced indoor cultivation.

Technical specifications

Inlet/outlet diameter: 250mm
Maximum air flow: 1650 m³/h
Operating voltage: 100-277 VAC, 50/60 Hz (automatic detection)
Number of blades: 7
Maximum static pressure: 814 Pa
Protection rating: IP44 (splash- and dust-proof)
Operating temperature: -20 to +60°C
Mean life time (MTTF): 50,000 hours (at 25°C)
Dimensions: 25.5 x 32.3 x 30 cm
Net weight: 6.55 kg

Includes

1 x Aero-Fan V-10 extractor - 315 mm
1 x Mounting plate
1 x Operating instructions
