Lifting device - Intelligent light lifter - LLT-1 - ThinkGrow
The ThinkGrow LLT-1 Intelligent Lamp Lift is an essential modular device for your indoor cultivation. It raises and lowers your horticultural lights up to 2.7 m with a capacity of 60 kg per unit. Easy to install and compatible with TrolMaster Hydro-X Pro, it ensures preventive control of the lightcis and synchronized lighting control, optimizing yield and productivity for all your growing installations.
You may also be interested in these products :
-
Your productLifting device -...
Product details
ThinkGrow LLT-1 - Intelligent light lifter
The ThinkGrow LLT-1 Intelligent Light-Transmitter is a key component of the ThinkGrow Modular Lifting System LED ThinkGrow modular lifting system. Designed to simplify installation and optimize the height of your fixtures, it allows you to raise and lower your horticultural lights in a single gesture. Ideal for indoor installations or vertical farms, the LLT-1 offers a scalable, secure and easy-to-implement solution, even for large-scale growing operations. Thanks to its patented design and synchronized mechanism, the LLT-1 guarantees smooth, predictive movementciswithout the need for complicated calculations or major work. Two people can set it up in just a few minutes.
Technical details
Synchronized modular system: Several LLT-1s can be connected in series (daisy-chain) for simultaneous, coordinated lifting.
Simplified installation: Quick two-person design, without special tools or complex adjustments.
Intelligent control: Compatible with the TrolMaster Hydro-X Pro controller for programming times and heights.
High lifting capacity: Up to 60 kg (132 lbs) per unit.
Maximum lifting height: 2.7 m (8.8 ft / 106 inch).
Robust materials: Motorized motor, position transducer, reinforced chassis and high-strength steel cables.
Scalable: Add or remove LLT-1 modules as required, without modifying the whole system.
Safety standard: Meets electrical and mechanical safety requirements (ETL).
Benefits
Pre-controlcis height control: Constantly maintains the ideal distance between LEDs and canopy.
Time-saving installation: Quick and easy to set up, without structural complexity.
Long-term reliability: Robust, certified design for long-lasting performance.
Flexibility to adapt: The modular system can be adapted to any configuration, large or small.
Optimized productivity: Facilitates maintenance and ensures lighting uniformity.
Increased profitability: Optimizes lighting efficiency throughout the growing cycle.
Technical specifications
Product type: Light lift LED intelligent modular
Lifting capacity: ≤ 60 kg (132 lbs) per unit
Lifting range: ≤ 2.7 m (8.8 ft / 106 in)
Power supply: 120 V/60 Hz or 240 V/50 Hz (stand-alone via Hydro-X controller)
Enviro-compatibility: Operating temperature 0°C to 40°C, humidity ≤ 90% RH
Unit weight: 2.5 kg
Connection: RJ-45 data cable for daisy-chain synchronization
Certifications: ETL, CE, FCC
Extended functionalities
Easy control via TrolMaster Hydro-X Pro controller.
Each module can be synchronized to raise or lower all luminaires simultaneously.
Pre-programmed raising/lowering times can be programmedcis and manage multiple independent zones.
Integration into the overall climate and lighting management system.
Manual mode operation via Lifter Remote Control (LRC-1) for instant adjustment.
Easy scaling: add as many LLT-1 modules as required to the existing chain.
The system automatically detects additional units without reconfiguring the network.
Opt for LLT-1 ThinkGrow Intelligent Light Riser for predictive controlcis luminaire height, save installation time and ensure long-term reliability. This modular, ETL-certified system offers the flexibility to adapt to your changing needs, facilitating maintenance, ensuring lighting uniformity and optimizing light efficiency throughout the growing cycle. With LLT-1, you gain in productivity and profitability by always maintaining the ideal distance between your LEDs and your canopy. Think smart: choose ThinkGrow.
datasheet
| Name | Lifting device - Intelligent light lifter - LLT-1 - ThinkGrow |
| Brand | ThinkGrow LED |
| Eco-contribution (€) | 1.75 |
| Source d'énergie | Filaire |
